The Darlington Bipolar Power Transistor is designed for general-purpose amplifier and low speed switching applications. TIP120, TIP121, TIP122 (NPN); TIP125, TIP126, TIP127 (PNP) are complementary devices.
The TIP125, TIP126, TIP127 is a 100V 5A 65W (PNP) Plastic Medium-Power Complementary Silicon Transistors. The devices are manufactured in planar technology with “base island” layout and monolithic Darlington configuration.
The TIP132TIP-132 132 is a 100V 8A 70W silicon Epitaxial-Base NPN Darlington Power Transistor in monolithic Darlington configuration, mounted in Jedec TO-220 plastic package.
The TIP140, TIP141 and TIP142 are 100V 10A 125W Silicon Epitaxial-Base NPN power transistors in monolithic Darlington configuration, mounted in TO-220A/B Package.
The TIP140, TIP141 and TIP142 are 100V 10A 125W Silicon Epitaxial-Base NPN power transistors in monolithic Darlington configuration, mounted in TO-218 Package.
The TIP145, TIP146 and TIP147 are 100V 10A 125W Silicon Epitaxial-Base PNP power transistors in monolithic Darlington configuration, mounted in TO-220A/B Package.
The TIP145, TIP146 and TIP147 are 100V 10A 125W Silicon Epitaxial-Base PNP power transistors in monolithic Darlington configuration, mounted in TO-218 Package.
The TIP31C is a base island technology NPN power transistor in TO-220 plastic package with better performances than the industry standard TIP31C that make this device suitable for audio, power linear and switching applications. The PNP type is TIP32C.
