XL7015 DC-DC Step Down or Buck Module
150৳
The XL7015 is a DC–DC buck type module is A highly efficient, high pressure step-down DC DC converter, provides the highest 0.8A output current capability, low ripple, excellent linear regulation and load regulation, up to A maximum of 80V input voltage
Description
The XL7015 is a DC – DC buck type module is A highly efficient, high pressure step-down DC – DC converter, provides the highest 0.8 A output current capability, low ripple, excellent linear regulation and load regulation, up to A maximum of 80 v input voltage, more than 2596 modules, etc. Chip built-in various protection mechanisms. Can be applied to electric vehicle controller, etc.
Parameter:
- 1. 5 v to 80 v input voltage range wide
- 2. The output voltage from 5 v to 20 v adjustable
- 3. The minimum pressure drop 1 v
- 4. 0.8 A biggest switch current
- 5. Recommend the output power is less than 7 w
- 6. Shut off built-in overheating protection, output short circuit protection, over current protection
- 7. Good linear with load regulation
- 8. The board size: 16 mm * 44 mm
Wiring instructions:
- 1. VIN: input voltage (5v – 80v)
- 2. The GND: input voltage side
- 3. The VOUT: output voltage (5v – 20v)
- 4. The GND: output voltage to end
Packing List:
1Pc * XL7015 DC-DC Step Down or Buck Module
